HP 95 MiD-MOUNT PLATFORM
The HP 95 Mid-Mount platform is designed for departments that have travel height restrictions or prefer a centrally located turntable.
The extruded aluminum aerial is exceptionally stable, and with only one set of extending stabilizers and auto-levelling system, is quick and easy to set up in tight locations.
With waterway flows up to 2000 GPM and a large mid-ship pump, the HP 95 platform has excellent fire-fighting capability.The extruded aluminum body features a large ladder tunnel and 300-to-500-gallon tank.
Specifications
- Body Extruded aluminum
- Chassis Typhoon or Cyclone chassis
- Engine Up to 605HP
- Aerial device 95’ welded extruded aluminum platform
Documents
-
1
-
2
-
3
-
4
-
1
1
Typhoon® or Cyclone® chassis,
Medium and long 4-door cabs available -
2
2
Body available in extruded aluminum
Available “truck company” body with no tank or pump -
3
3
Hale or Waterous pump up to 2000 GPM
Up to 500 gallon water tank -
4
4
95’ welded extruded aluminum platform with 2.5 to 1 structural safety factor,
Rated at 1305 lbs dry (1000 lbs firefighters and 305 lbs equipment); 805 lbs wet (500 lbs firefighters and 305 lbs equipment)
