HR 100
The HR 100 with a tandem rear axle provides additional storage space and weight carrying than single rear axle units and is available as a Quint or Truck Company.
The crisscross under-slung jacks have a narrow 12’ spread that require very little space to deploy. The aerial features the ToughTruss ladder design with a 500 lb tip load (wet or dry).
Specifications
- Body Extruded aluminum body construction
- Chassis Typhoon® or Cyclone®
- Engine Up to 605HP
- Aerial device 100’ extruded aluminum ladder
Documents
-
1
-
2
-
3
-
4
-
5
-
1
1
BUMPER EXTENSIONS
Severe duty front bumper extensions are available with options such as low pre-connected handlines or hydraulic tools to meet department requirements. -
2
2
THE STRONGEST CAB IN THE INDUSTRY
EXCEEDING NFPA REQUIREMENTS
Keep crews safe with the cab that withstands more than five times the static roof load and more than twice the frontal impact required by the NFPA. -
3
3
FIREFIGHTING SYSTEM ENGINEERED TO YOUR REQUIREMENTS
Hale®, MAC1®, Waterous® or Darley® midship pumps are available.
E-ONE's exclusive eMAX™ is also available, providing low pre-connected handlines, additional storage space and enclosed pump panel. -
4
4
ADVANCED AERIAL CONTROL SYSTEM
The electric over hydraulic Advanced Aerial Control System provides smooth ladder operation. Conventional direct hydraulic controls are also available. -
5
5
COMPACT OUTRIGGERS
QUICK SET UP WITH A NARROW JACK SPREAD
This aerial features crisscross under-slung outriggers with only a 12' spread. This design is easy to work around, maximizes compartment space, and sets up fast.
